Plate evaporator is a kind of equipment that uses high-efficiency heat exchange plates to evaporate and concentrate the medium continuously. Compared with traditional shell and tube evaporator, it has significant advantages such as compact structure, energy saving and high efficiency, small footprint and convenient maintenance. Plate evaporator adopts compact structure and high-efficiency heat exchange plates, which is suitable for low-temperature concentration of heat-sensitive juices (such as orange juice, apple juice, pineapple juice, grape juice, etc.) to avoid loss of flavor and nutrients.
| Industry Challenges | Our Solutions |
|---|---|
|
❌ High-Temperature Damage 40% vitamin C loss, flavor deterioration from aroma volatilization |
✅ Low-Temperature Preservation Gentle evaporation at 40-65℃, vitamin retention rate >92% |
|
❌ Sugar Coking Requires hourly shutdowns for cleaning above 70°Brix |
✅ Anti-Scaling Turbulence Design Mirror-polished channels + pulsed flushing, 2000h continuous operation |
|
❌ Acid Corrosion Standard equipment lifespan <2 years under pH＜3 conditions |
✅ Super-Corrosion Resistance Titanium alloy + NSF-certified EPDM seals |
✅ Processing capacity requirements: Select the appropriate equipment model and specifications based on your daily/hourly processing volume.
✅ Concentration target concentration: Different target concentrations will affect the selection and energy consumption of the equipment.
✅ Juice types and characteristics: Consider the viscosity, acidity, solid content and other characteristics of different juices.
✅ Compatibility with existing production lines: Consider the connection and integration of new equipment with existing production lines.
✅ Utility support: Evaluate the supply capacity of utilities such as steam, cooling water, and electricity.
✅ Evaporation Capacity: 2-20 tons/hour (Fresh juice processing capacity)
✅ Material Composition: Evaporation Section: Titanium plates Preheating Section: 316L stainless steel
✅ Key Features: Auto CIP Cleaning System Viscosity-Adaptive Frequency Control
| Metric | Traditional Evaporator (Juice Concentration) | Plate Evaporator (Juice Concentration) | Advantages |
|---|---|---|---|
| Flavor Retention | Poor | Superior | Higher product quality |
| Processing Time | Longer | Shorter | Increased production efficiency |
| Energy Consumption | Higher | Lower | Reduced operational costs |
| Cleaning & Maintenance | Complex | Simplified | Less downtime & labor costs |
| Versatility | Limited | Enhanced | Adapts to diverse juice types |
✅ Heat pump integrated system: Steam energy consumption is reduced by 70%, suitable for high-viscosity materials such as mango pulp
✅ Online concentration monitor: Real-time control of evaporation parameters, product volatility is reduced from ±3% to ±0.5%
✅ Modular expansion design: Initial investment is reduced by 40%, and production capacity is expanded in stages according to market demand
Production capacity: 20 tons of concentrate per day
Investment cost: about $160,000
Operation cost savings: about $45,000 per year
12-month payback
24-hour unmanned operation through PLC system
👉 Just provide the following data to make a project budget and equipment configuration suggestions for you free of charge:
✅ Daily juice processing volume (tons/day)
✅ Initial concentration and target concentration
✅ Available steam pressure and cooling conditions
✅ Installation address and plant size
✅ Juice type (such as orange juice, grape juice, etc.)
